Diameter: DN 15-200 (1/2"-8")
Pressure: PN 16 - PN 25 - PN 40
Temperature: 400 °C maximum
Material:
GJL250 Cast Iron
0.7040 Ductile Iron
1.0619 Steel Casting
1.4408 Stainless Steel Casting
Connection type:
DIN EN 1092-2 with flanges
For gears DIN EN ISO 228-1 For sockets
External dimensions DIN EN 12760
Colors:
Cast Iron - Gray
Ductile Iron - Green
Cast Steel - Blue
Stainless Steel Casting - Metallic
Fluids used
• Steam
• Water, hot water, superheated water
• Compressed air, LPG
• Fuel
• Hot oil
• Various gases (such as oxygen, hydrogen, nitrogen)
• Heat transfer oils
• Acid etc. in all fluids such as chemicals
Advantages
• Does not contain asbestos
• Provides energy savings
• Does not require constant maintenance
• Does not leak to the atmosphere
• Does not pollute the environment
• No wear on the sealing surface
• Economical service is easy
• Rings can be changed while the valve is connected to the installation.
Sectors Used
• Energy production
• Refineries
• Petrochemical plants
• Chemical industry
• Food facilities
• Paper mills
• Iron and Steel factories
• Central Heating
• Tobacco factories
